Most delays on a fit-out or joinery package don't begin on site — they begin in the drawings. When the client pictures one thing, the contractor prices another, and the installer builds a third, the gap only shows up once material is cut and time is spent. Shop drawings exist to close that gap: a single, precise set that states exactly what will be made, how it fits, and what it will look like — before anyone commits.
The trouble is that most shop drawings are hard to read. Flat, line-only AutoCAD sheets produced by offshore volume shops are technically complete but visually impenetrable to a non-technical project manager or an end client. They approve what they cannot fully picture, and the misunderstanding surfaces at installation — as a variation, a delay, or a remake.
We draw differently. Every set we produce is modelled in SolidWorks and issued as shaded, three-dimensional shop drawings — the component shown as it will genuinely look, alongside the dimensions, sections and specifications the workshop needs. Your client sees the finished piece and signs off with confidence; your installers get a set they can build from without a phone call.
What a DesignAs shop drawing set includes
One organised, clearly named package — issued in the formats your workshop, your machines and your client all need.
Shop & GA drawings
General arrangement, plans, elevations and sections that place every element in the space and show how it goes together.
Fabrication & workshop drawings
Fully dimensioned detail drawings — joints, fixings, materials and tolerances — ready for the shop floor.
Cutting lists & schedules
Panel schedules, cutting lists, and hardware and ironmongery schedules that make accurate quoting and ordering possible.
CNC-ready files
DWG, DXF, STEP and native SolidWorks files that drop straight into your machines and your AutoCAD sets.
Shaded 3D views & renders
Shaded and photorealistic views for client sign-off, so approval happens on paper — not on site.
Submittal-ready packages
Clear, organised, clearly named sets suitable for submittals and client approval under JCT or NEC contracts.
Why shaded SolidWorks beats flat offshore AutoCAD
The offshore volume shops — the BluEnts, Hitechs and A2Zs of the world — compete on price and turn out flat, line-only AutoCAD sheets by the thousand. They are drawing for a detailer who already knows what the finished item looks like. Your client and your site team don't.
We are a UK studio working in SolidWorks, in your timezone. Because we model in 3D, every sheet can be issued shaded — the item shown solid and lit, exactly as it will be built — so a project manager can read it at a glance and a client can approve it without a technical translation. We're fluent in how UK packages are run, from GA sign-off to submittals under JCT and NEC contracts.
The result is fewer questions on site, fewer variations, and a set that protects everyone: you priced what you drew, and you built what the client approved.
A sample client sign-off set — shaded views a non-technical client can read
Who we produce shop drawings for
Main & principal contractors
Overflow drawing work and complete joinery packages produced to your programme — without carrying an in-house CAD team.
Fit-out contractors
Commercial and retail fit-out drawn end to end: reception desks, feature walls, built-in furniture and casework, ready for installation.
Shopfitters
Shopfitting shop drawings and CNC-ready files for counters, display, and bespoke retail joinery, drawn to be built at pace.
Commercial joinery subcontractors
Detailed commercial joinery drawings with cutting lists and schedules — everything your workshop needs to manufacture accurately.
From concept to shaded shop drawings
Send your concept
Architect's drawings, a sketch, a site survey or an existing model — whatever you have. We confirm scope and send a tailored quote within 48 hours.
We model & draw
General arrangement agreed first, then fully detailed shaded shop drawings, fabrication drawings, cutting lists and CNC-ready files — all in SolidWorks.
Your client approves
Shaded views make sign-off simple — the client sees the finished piece and approves on paper. At sign-off, the design is locked.
Your installers build
Manufacture-ready files go to the workshop and to site. Any changes after sign-off are quoted before we begin.
Accuracy guaranteed, cost agreed upfront
If a delivered drawing doesn't match the agreed design intent, we correct it at no cost and as a priority. All changes — refinements, updates, or new directions — are quoted before work begins, so you always know the cost upfront. Pricing is matched to the project: a project fee, time-based, or staged across a programme — whichever suits the package. See our corrections, changes and scope policy for the detail.
Prefer to see the service at a glance first? Our quote overview page walks through the deliverables and the sign-off set in short. When you're ready, send the brief and we'll come back within 48 hours.
